• High precision timing chip and V-Path calibration model used for precision measurement • Probe gain adjustable • Sound velocity and thickness information can be stored completely • Mini-USB interface used for communication • Support online measurement • Contrast adjustable and backlight selectable • Host Software upgradable | • Thickness range: 0.75 - 400 mm (steel, with different probe) • Sound velocity range: 1 - 9999 m/s • Displaying accuracy: 1m/s , 0.01mm , 0.001inch • Measuring error: <10mm :±0.05mm, ≥10mm :(±0.5% * H)mm • Measurement period: 4 times per second • Measurement frequency: 5MHz, 2MHz, 7.5MHz, 3MHz • Display: FSTN digital LCD with backlight • Display contents: Sound velocity, Thickness, Stability, Battery, Measuring Mode, etc. • Gain adjutable: 3 level • Storage: 500 measurements, including sound velocity, thickness, etc. • Communication: Mini-USB interface, virtual serial port protocol, support online measurement, host software upgradable • Power Supply: 3 * AAA alkaline batteries • Power off: Timeout power off, and low battery power off • Temperature: Usage: -10 ~ 50 °C, Store: -30 ~ 60 °C • Shape size: 150mm * 70mm * 30mm • Material: ABS and PC alloy • Weight: 180g |
![]() | |
• Adapted to measure the sound velocity of good conductor for ultrasonic, such as metal(steel, cast iron, aluminum, copper), plastic, ceramic, glass, glass fiber and so on. • 3 level gain adjustable, suitable for a variety of applications • Zero Calibration can be used for system error auto correction • Thickness can be measured by a known sound velocity sample piece • Single point measurement and scan mode support • Stability indicator for measuring status monitoring • Battery indicator for battery quantity monitoring • Able to communicate with PC | |
